FEATURES:
􀂾 Advanced driving system w ith section, trimming, fast forward, backward etc
􀂾 LCD screen shows section and trimming thickness range, numbers of section and trimming
􀂾 Section and trimming mode can be finished by controlling systems
􀂾 Handw heel can be locked at any position to assure user's safety
􀂾 Universal cassette clamp and standard specimen clamp, with emergency stop system
􀂾 Large waste tray, easy to unload

SPECIFICATIONS:
Section thickness range:
 0.25～60μm
0.25～1μm increment 0.25μm
1～10μm increment 1μm
10～20μm increment 2μm
20～60μm increment 5μm

Trimming thickness range: 0.25～60μm
Minimum setting value: 0.25μm
Object feed: 28mm
Vertical stroke: 60mm
Maximum specimen size: 50 x 50mm
Precision error: ±5%
Working Voltage: AC220V/50Hz, AC110V/60Hz
Pow er: 150VA
Dimension: 540x200x290mm
Net weight: 24kg
