FEATURES:
􀂾 Vacuum for accelerating the speed of Tissue processing
􀂾 Microprocessor control, LCD display
􀂾 With exchange jar and change place control draw perch
􀂾 Pow er-off alarm and obstacle alarm
􀂾 Agitation dehydrate mode so tissue and solvent, paraffin meet, thereby well effect
􀂾 Wide time range: delay time 59hr59min. Each jar working hours longest 59hr59min,time least distance 1 min
􀂾 Vacuum in each jar can be set separately
􀂾 Wax jar adopts constant temperature control system with high temperature accuracy, defending pollution and canker
􀂾 Adopting 9 slices 1.2L medicine aquarium, for observing tissue change
􀂾 Optional: Backup battery working for 4-16 hours after power off

SPECIFICATIONS:
Steps of processing tissue: 12steps
Glass container: Quantity 9, capacity1.2L
Wax container: Quantity 3, capacity1.2 L
Temperature range: 45～85℃±3℃
Process: Each cup working hours0～59hr59min
Delay process: 0～59hr59min
Vacuum: 0.053 Mpa
Vertically reciprocative motion of tissue basket: 3times/min
Tissue basket specification:
   Barrel tissue basket: ￠95x80mm
   Layer nacelle: ￠95x80mm, 5 layers
Weight: 60kg
Dimension: 670x550x680(diameter x height x tiptop, mm)
Rated voltage: AC220V/50Hz, 110V/60Hz
Pow er: 500W
Room conditions :
   Temperature range: ＋5℃～40℃
    Humidity: <85％（20±5℃）
